OWNER’S MANUAL
Tilt Wheelchair
5.1 Stability
Before using ANY recline position of
this wheelchair, make sure the rear
wheels are in the best position to
maintain the stability of the
wheelchair.
The seat height, seat angle, pivot
point of seat frame, seating system,
caster position, size and position of
the rear wheels, as well as the user
condition directly relate to the
stability of the wheelchair.
Any change to one or any
combination above may cause the
wheelchair to lose stability. These
adjustments MUST be performed by
an authorized dealer or qualified
technician.
Before using the recliner option,
make sure the anti-tipper wheel
assemblies are in the lowest
adjustment hole. (Adjustment hole
closest to the ground/floor).
5.2 Safety information
1. Unless otherwise noted, all
service and adjustment should
be performed while the
wheelchair is noccupied.
2. ALWAYS keep hands and fingers
clear of moving parts to avoid
injury.
3. DO NOT attempt to move up or
down an incline with a water, ice
or oil film.
4. DO NOT operate on roads, streets
or highways.
5. DO NOT attempt to ride over
curbs or obstacles. Doing so may
cause your wheelchair to tip over
and cause bodily harm to you or
damage to the wheelchair.
6. DO NOT attempt to reach objects
if you have to move forward in
the seat.
7. DO NOT attempt to reach objects
if you have to pick them up from
the floor by reaching down
between your knees.
8. DO NOT lean over the top of the
back upholstery to reach objects
behind you, as this may cause
the wheelchair to tip over.
9. DO NOT shift your weight or sitting
position toward the direction you
are reaching as the wheelchair
may tip over.
10. DO NOT attempt to stop a
moving wheelchair with wheel
locks. Wheel locks are not
brakes.
11. DO NOT tip the wheelchair
without assistance.
12. DO NOT use an escalator to
move a wheelchair between
floors. Serious bodily injury may
occur.
13. DO NOT attempt to lift the
wheelchair by any removable
(detachable) parts. Lifting by
means of any removable
(detachable) parts of the
wheelchair may result in injury
to the user or damage to the
wheelchair.
14. DO NOT stand on the frame of
the wheelchair.
15. DO NOT use the footplate as a
platform. When getting in or
out of the wheelchair, make
sure that the footplates are in
the upward position.
5.3 Self-lock device
NOTE: For this procedure, refer to
Figure 12.
The wheel lock is not a brake, DO
NOT use the wheel lock to slow or
stop the wheelchair. The wheel lock
is used to prevent movement while
stopped.
Pull up the wheel lock handle until
the rear wheel can not move, put
the self-locker to a locking position,
then the wheelchair self-locked.
Pull up again on the wheel lock
handle to release the self-locker.
5.4 Anti-tipper
NOTE: The anti-tippers must
maintain a 1- 1/2 to 2-inch
clearance between the bottom of
the anti- tipper wheels and the floor.
NOTE: For this procedure, refer to
Figure 13.
Operate the bolt to install, remove,
or adjust the anti-tipper.
NOTE: Anti-tippers MUST be fully
engaged and the bolt fully
protruding out of the adjustment
holes.
Please review before use.
5.5 Recliner
NOTE: For this procedure, refer to
Figure 14.
The gas spring controls the recline of
the wheelchair. There are two
handles of this wheelchair to control
two gas springs, the left is for seat
recline and the right is for back
recline.
Pull up the adjust handle to engage
the gas spring, release the handle
when the recliner has reached the
angle you want.
The angle range between the seat
and the floor is 0 ° -30° , and
between the back and the floor is
90-180°
