6
BLOWER INSTALLATION (Continued)
FOR SPA BATHS:
- Unless already fitted by your spa bath supplier, Onga recommend the
installation to follow either Diagram 1 or 2, dependant upon the blower
positioning.
- Place the Whispair blower rubber connection over the PVC pipe. DO
NOT glue the spa blower rubber connection to the PVC pipe.
- Tighten the hose clamp (supplied), be careful not to overtighten.
- Fix blower to mounting frame or base.
- Insert the blower power lead into a correctly rated wall socket.
- Allow adequate access for servicing blower & piping.
AIRSWITCH MODELS
- A roll of 6 metre air tube is supplied (Australia / New Zealand models only),
attach one end of the tube onto the nipple of the air button fitted on the spa bath,
attach the other end of the air line onto the blower (remove Left-hand filter pad;
insert air tube through the slot provided; insert air tube onto air switch; replace
filter pad).
Trim excess tube. Do not wrap around pipework.
