Onix 1832 - Parts Breakdown and Service; PARTS BREAKDOWN; Parts List

372 Old US Highway 52 South
Mount Airy, NC 27030
811
Page 4
Model: Product Type:
ONYX 1/2" NANO ANGLE
IMPACT WRENCH - 415FT/LB
1832
Call 1.800.221.9705 for questions concerning performance of
the product or other inquiries.
PARTS BREAKDOWN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1832-01
1832-02
1822-03
1822-05
1822-04
1832-06
1832-07
1832-08
1832-09
1822-10
1832-11
1822-18
1822-19
1822-20
1822-21
1822-22
1822-23
1822-24
1822-25
1822-26
1822-27
1822-28
1822-29
1822-30
1822-31
1822-32
1832-27
1832-28
Socket Cap Screw W/Washer
Hammer Housing
Hammer Case Bushing
O-Ring
Retainer Ring
Drive Anvil
Hammer Pin
Hammer Cage
Hammer Cam
Hammer Housing Gasket
Housing
Ball Bearing R8
Front End Plate
Cylinder
Dowel Iiner
Rotor
Rotor Blade
Rear End Plate
Ball Bearing R8
Motor Housing Gasket
Housing Cap
O-Ring
E-Ring
Regulator Knob
Regulator Valve Detent Spring
Regulator Valve Detent Ball
O-Ring
Air Exhaust Deflector
Index Part No. QtyDescription
8
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
6
1
1
1
1
1
1
1
1
1
2
1
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
1832-29
1832-30
1832-31
1832-32
1832-33
1832-34
1832-35
1832-36
1832-37
1832-38
1832-39
1832-40
1832-41
1832-42
1832-43
Handle
Spring Pin
Conjunction Screw
O-Ring
Retainer Ring
Throttle Bushing
Throttle Valve
Throttle Spring
O-Ring
Air Inlet Bushing
Handle Grip
Spring Pin
O-Ring
Trigger Valve
Trigger
Index Part No. QtyDescription
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
Parts List
