Get to Know Your Portable Power Hub
Get to Know Your Portable Power HubGet to Know Your Portable Power Hub
2
3
4
5
6
7
.
Need help? We're here for you every day 7 a.m. – 9 p.m. CST.
1-888-516-2630 Give us a call!
Portable Power Hub
Quick Start Guide
What’s in the Box?
Check to make sure you
have everything below.
1. Portable Power Hub
2. Quick Start Guide
3. 15V 2A adapter
2
3
1
Quick Start Guide
15
17
18
19
20
21
23 24 25 26 27
15.Ambient Light
16.Ambient Light Button
17.DC Input Port
18.Flashlight Light
19.Flashlight Light Button
20.AC Output Port
21.AC Output Control Button
22.LED Indicator for speaker and Weather Radio
23.Power on / off (Speaker)
24.Volume Down / Previous Track
25.Volume Up / Next Track
26.Bluetooth / Play / Pause
27.NOAA Weather Radio
Handle
Automobile Auxiliary Power
Outlet
LCD Di
splay
LED Ind
icator for Powerhub
Main Power Button Display
Control Button DC Output
Ports
1.
2.
3.
4.
5.
6.
7.
USB-A Output Ports
USB-C Output Port
Power Delivery USB-C Port
USB Output Control Button
LED Indicator for DC Ports
DC Output Control Button
LED Indicator for USB Ports
8.
9.
10.
11.
12.
13.
14.
100069441
6 81131 41437 1
Device to Portable Power Hub Device to Portable Power Hub
TIPS:
LCD Display Device to Portable Power Hub
INPUT
Output
BATTERY LEVEL
OVERLOAD WARNING
TEMPERATURE WARNING
INPUT: Shows power (watts) amount going into the Portable Power
Hub while charging.
OUTPUT: Shows power (watts) amount your devices are using while
plugged into the Portable Power Hub.
BATTERY LEVEL: Shows in increments of 10, up to 100 capacity.
When charging your Portable Power Hub you will notice a battery
segment blinking, this indicates the current charge status. Once fully
charged, all battery segments will be lit and remain white solid.
OVERLOAD WARNING: Power draw exceeds port's maximum
allowance, indicator by the button will flash red. You need
to remove the device in corresponding port first, and
then press the button of the port to reset.
TEMPERATURE WARNING:The unit is over-heating. Disconnect the
device, and press main power button again.
IMPORTANT: Press & hold 10 seconds to activate the Portable
Power Hub for INITIAL USE ONLY.
*By AC output port *
By DC output
ports
*By USB-A output ports
Next time, you can follow below steps to charge your device.
PRESS & HOLD
INITIAL USE ONLY
1.When any of the control buttons are turned on, even if no devices
are being charged, there will still be a certain amount of no-load
power consumption. Therefore, it’s better to turn off the control
buttons after using to avoid draining power.
2.You'll know the output port is turned on when the green LED light
by the button is solid.
3.Press the "DISPLAY" button to turn on/off the LCD display.
4.The max power output of the AC port is 200W. If you use the AC
port for devices greater than 200W, Power Hub will automatically
turns off.
5.When Power Hub has only 1% battery left, the Power Level and
Percentage of Capacity Left will flicker to remind you to recharge
Power Hub.
1
3
2
2
3
3
Light Mode Charging Your Portable Power Hub
Flashlight Mode
Press once to toggle between low brightness, full brightness, SOS,
and no brightness mode.
Ambient Light Mode
Press once to toggle between low brightness, medium brightness,
high brightness and no brightness.
* You can charge your Portable Power Hub with DC IN port and
USB-C PD Port at the same time.
USB-C PD Port
Press Once
NOAA Weather Radio
Hints and TipsPower on / o the Speaker Bluetooth® Connection
Press & hold to power on / off the speaker In Bluetooth mode, activate the Bluetooth function on your device
and search Bluetooth devices, then select “onn. POWERHOUSE” to
start connecting.
Press once WB button to search for Weather Band, the LED
indicator will be solid green. The radio will find the strongest
signal Weather Band channel from the local radio.
Press & hold WB button to activate or exit auto-wake-up mode.
The LED indicator will flash slowly, and you will receive every
advisory, watch and warning automatically once activated.
Weather Band: 162.400~162.550MHz
Portable Power Hub will automatically turns off when the power of
the device exceeds the rated output power (200W). The LCD
di
splay will alert when the power system detects that the device
being used is shorted or overloaded. Please confirm whether the
device parameter specifications meet the scope of the Portable
Power Hub before using it.
How to clear the automatic protection after it is activated?
A:
If the OVERLOAD mark is lit on LCD display
Disconnect the device.
Pr
ess once the main power button to clear the automatic
protection.
B: If the LCD display is completely black
Disconnect the device.
Charge the Portable Power Hub for 2~3 minutes.
Press once the main power button to clear the automatic
protection.
To pres
erve battery lifespan, use and recharge at least once
every 3 months.
onn. POWERHOUSE
ON/OFF
Press & Hold
Search Devices
Press Once
Play / Pause
Press & Hold auto-wake-up mode
Press Once Search for Weather Band
November 27, 2021_V2
* By automobile
auxiliary power outlet
1
2
1
2
3
AC Socket
Solar Panel
Car Charger
(included)
(not included)
(not included)
(not included)
Preferred
Press
Once
Press
Once
Press
Once
SOS
WB
2s
10s
3s
X1
Press Once
2
3
X1
Press Once
X1
Press Once
X1
Press Once
Press & Hold
1
3s
Press & Hold
1 2
3s
Press & Hold
1
3s
Press & Hold
Press & Hold
Press Once
Press & Hold
Press Once
Press & Hold
*
By DC IN Port
*
By Power Delivery USB-C Port
