MEASUREMENT LOG HV-SYSTEM CORSA-E RALLY
1. CHECK CENTRAL GROUND POINT
 Target value: Less than 10 mꭥ
Important: This ground point is used for all following measurements.
Important: The resistance value measured here must be added to all following potential equlization
measurements.
Measuremt point from
battery negative to main
relay (contact to body)
mΩ
