Documentation

Documentation, drivers and software updates for the

H-29(EU) are available at:www.opticon.com

Opticon Sensors Europe BV

Opaallaan 35, 2132 XV Hoofddorp, the Netherlands.

is subject to change without prior notice.

For availability, contact your local representative.

SD / SIM Card Installation (H-29EU model)

1. Turn off the H-29EU or put it in battery swap mode

2. Remove the battery cover

3. Remove the battery pack by pulling the tab on the end

of the battery

4. Lift the retaining door

5. Please see the back view

6. Insert the micro SD card into the left slot

7. Insert the SIM card into the right slot

8. Insert the battery pack into the battery compartment

9. Restore the battery cover and lock the battery cover

lock switch

Barcode Data Capture

To scan a barcode label:

1. Point the scan window at the barcode.

2. Tap scan on the screen or press one of the scan buttons

on the H-29(EU). The imager will project a green

aiming bar. The green aiming bar is used to position the

barcode or object within the field of view of the imager.

3. Ensure the entire barcode is within the width area

formed by the green aiming bar, then either wait for

the timeout or release the scan key to capture the

image. A white beam will illuminates the barcode to

capture and decode it.

FCC Compliance for H-29

This Device complies with Part 15 of the FCC rules,

operation is subject to the following two conditions.

(1) This device may not cause harmful interference and,

(2) This device must accept any interference received,

including interference that may cause undesired operation.

This device has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates uses and

can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur

in a particular installation if this equipment does cause

harmful interference to radio or television reception, which

can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

General Safety Rules

Please read this Guide thoroughly and carefully before you start using

this device. Use only the components and accessories supplied by the

manufacturer for H-29(EU) you are using.

Do not attempt to disassemble H-29(EU), as it does not contain parts that

can be repaired by the user. Any tampering will void the warranty. When

replacing the battery pack or at the end of life of H-29(EU) disposal must be

performed in compliance with the laws in force in your jurisdiction. Do not

submerge H-29(EU) in any liquid (water, detergent, etc).

For Safe Use Concern, Please Pay Special Attention on the Following Notices:

The manufacturer has taken safety as first priority during design stage. To

avoid any potential accident, please be cautious on the following alert points:

• Please do not stock this device under conditions of high temperature

which will cause the battery to become hot, fire, or broken etc. leading to

failure and safety concerns.

• When the charging time is noticed longer than standard required

(CHARGING LED, RED, is still ON), please stop charging immediately.

• Please charge this device in place without any water-spray or moisture.

• Ensure that the AC adapter can freely dissipate its heat, don’t cover the AC

adapter with objects, such as curtains.

• Never use damaged AC adapters, immediately replace it with a new

approved AC adapter.

• Please do not put any heavy weight on top of this device as it might cause

device enclosure crack then lead to cutting injury.

• Please do not use wet hand to pull out the AC adapter which might cause

electric shock.

• Please do not use H-29(EU) AC adapter on any other different devices.

• Please do not put the device into water which may cause short-circuit or fire.

• Please do not put this device in place close to open fire.

• If the power or USB cable is seriously twisted or broken, please stop using

immediately or it may cause electric shock, short-circuit, or fire.

• Please stop using immediately when there is any unusual smell or overheat

during charging or operation.

• Please stop using immediately when there is any liquid or dew on the device.

• Please do not use the AC adapter outdoor. Please do not wrap the AC

adapter with cloth which will block heat dissipation and will cause electric

shock or fire.

• Except charging, please remove the AC adapter plug from the wall AC

outlet socket or it will cause fire accident.

Important Notices When Using

• Before replacing battery pack due to failure, shortened life, or any other

unusual behavior, please confirm if the device has been used correctly and

there has no user operation issue involved.

• It is possible there will be some missed data or interference encountered

during the wireless transmission. It is not a situation can be controlled by

the manufacturer.

• Please do not use any alcohol, benzene, organic solvent, cleaner liquid, or

steel-wool on the surface of this device.

• Please do not scratch the surface of Scan Window in any way as which will

cause problem on barcode scanning.

Audio Safety

To prevent possible hearing damage, do no listen at high volume for long periods.

European Union Regulatory Notes

Hereby, Opticon Sensors Europe B.V. declares that the radio equipment type H-29(EU)

is in compliance with Directive 2014/53/EU. The WiFi operating in the bands 5150 –

5350 MHz shall be restricted to indoor use for countries listed in the table below:

AT BE BG CZ DK EE FR

DE IS IE IT EL ES CY

LV LI LT LU HU MT NL

NO PL PT RO SI SK TR

FI SE CH UK HR

The full text of the Declaration of Conformity is available at the following internet

address: https://opticon.com/product/h-29/

SAR Compliance (H-29EU) SAR Compliance (H-29)

SAR Information (for EU): SAR Information (for EU):

Head: 0.328 W/kg@ 10g (CE) Head: 0.288 W/kg@ 10g (CE)

Body: 1.600 W/kg@ 10g (CE) Body: 0.320 W/kg@ 10g CE)

Body - worn Operation

This device was tested for typical body-worn operations. A minimum separation

distance must be maintained between the user’s body and the handset, including the

antenna: 0.5 cm to comply with the RF exposure requirements in Europe third-party

belt-clips, holsters and similar accessories used by this device should not contain any

metallic components. Body-warn accessories that do not meet these requirements

may not comply with RF exposure requirements and should be avoided.

Power and Frequency Ranges

H-29EU

Radio Type Description Frequency Maximum

Output

Bluetooth Bluetooth BR+EDR 2400~2483.5 MHz 4dBm

Bluetooth 4.0-LE 2400~2483.5 MHz 4dBm

WLAN 2.4GHz 2400~2483.5 MHz 17dBm

5GHz 5150~5350 MHz 21dBm

5470~5725 MHz 22dBm

GSM GSM 900 880~915 MHz 32dBm

GSM 1800 1710~1785 MHz 30.5dBm

WCDMA WCDMA Band I 1920~1980 MHz 24dBm

WCDMA Band VIII 880~915 MHz 24dBm

LTE LTE Band 1 1920~1980 MHz 23dBm

LTE Band 3 1710~1785 MHz 23dBm

LTE Band 7 2500~2570 MHz 23dBm

LTE Band 8 880~915 MHz 23dBm

LTE Band 20 832~862 MHz 23dBm

LTE Band 38 2570~2620 MHz 24dBm

LTE Band 40 2300~2400 MHz 23dBm

other NFC 13.56 MHz

GPS 1575.42 MHz

H-29
