Front Panel Controls
8
The Scout frequency memory is protected and will not lose data unless there is an abrupt battery failure
or disconnection.
To CLEAR the memory in the Scout, hold down the GATE/RECALL/ CLEAR push-button while
switching the power off.
GATE GATE MEASUREMENT MEASUREMENT EXAMPLE
SETTING TIME TIME RESOLUTION (MHz)
1 800uS 8mS 10KHz 162.55
2 8mS 14mS 1KHz 162.550
3 80mS 90mS 100Hz 162.5500
4 800mS 810mS 10Hz 162.55000
Table 1 Scout Gate Settings
