Front Panel Operation – OP850
IL Mode: Pressing the dB/dBm button in IL mode executes a reference sequence.
For single wavelength devices, or dual wavelength instruments with individual ports
this involves taking the reference at the selected wavelength. For dual wavelength
instruments this involves taking the reference for the first wavelength, then repeats the
same for the second wavelength. The referencing cycle can take up to 5 seconds.
Mode Selection
For the OP850, the mode selection buttons switch between modes.
Channel Selection
For the OP850, the channel selection buttons change the active channel.
