Remove Front Indicator Panel
Remove Front Indicator Panel
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the front indicator panel from Oracle Database Appliance
Version 1.
1.
Prepare the system for service.
a.
Power off the system (both server nodes).
See “Shutting Down a Server Node and Powering Off the System” on page 143.
b.
Disconnect the power cords from the system.
c.
If the system is installed in a rack, remove it.
See the Oracle Database Appliance Owner's Guide for information on racking the system
chassis.
d.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 146.
2.
Remove the adjacent disk drives [1].
Be sure to mark them so that you can return them to the correct drive bays later.
3.
Unscrew the three Phillips screws from the back of the ear bezel [2].
4.
Remove four more Phillips screws from the inside of the drive bays [3].
5.
Remove the ear bezel [4].
The ear bezel and indicator panels remain connected to the ribbon cables.
Appendix A • Servicing the Oracle Database Appliance Version 1 223
