Oras Optima 2700F - Page 17

2705F
ø 33 - 35
l = 350
max30
G 3/8
98
66
33°
161
144
G 1 1/4
20 - 80
ø 63
23
ø 52
204
154 120
32
3 x l = 400
185
G 3/8
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
l = 1500
(EMC 2004/108/EY)
2715F
ø 33 - 35
l = 350
max30
G 3/8
98
66
33°
161
144
23
ø 52
204
154 120
32
3 x l = 400
185
G 3/8
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
G 1/2
l = 1500
(EMC 2004/108/EY)
EN 817, EN 15091
I (ISO 3822)
100 - 1000 kPa
0.13 l/s (300 kPa)
170 kPa (0.1 l/s)
max. +70°C
EN 817, EN 15091
I (ISO 3822)
100 - 1000 kPa
0.13 l/s (300 kPa)
170 kPa (0.1 l/s)
max. +70°C
l =400
l =400
STF VTT-RTH-00063-14
VA 1.42/20420
Sintef Nr. 3082
STF VTT-RTH-00063-14
VA 1.42/20420
17 (56)
