Orban Optimod-AM 9400 User Manual

OPTIMOD-AM DIGITAL TECHNICAL DATA
6-19
PART # DESCRIPTION COMPONENT IDENTIFIER
C644, C648, C651, C657, C658,
C661, C663, C666, C667, C671,
C673
21154.433.01
CAPACITOR, CERAMIC, 10%, X7R,
0.33UF, SMT
C503
21137.447.01
CAPACITOR, CERAMIC, 25V, 10%,
0.47UF, SMT
C113, C117, C234, C235, C256,
C257
20123.100.01
RESISTOR, METAL FILM, 1/8W, 1%,
1.00K
R521, R600, R601, R602, R603
20126.100.01
RESISTOR, METAL FILM, 1/8W, 1%,
1.00M, SMT
R142, R152, R247, R248, R292,
R295
21318.510.01 CAPACITOR, P, 35V, 10%, 1UF
C200, C201, C232, C244, C246,
C248, C515, C516, C521
22101.001.01 DIODE, 1N4148W, SMT CR101, CR102, CR106, CR107
29522.000.01 INDUCTOR, 1.2mH, 5%, IM-10-22
L204, L205, L206, L207, L208, L210,
L212, L214
20123.150.01
RESISTOR, METAL FILM, 1/8W, 1%,
1.50K, SMT
R131, R134, R140, R141, R144,
R146
20041.154.01
RESISTOR, METAL FILM, 1/8W, 1%,
1.54K
R159, R160, R161, R162
20130.162.01
RESISTOR, METAL FILM, 1/8W, 1%,
1.62K, SMT
R132, R153, R156, R157, R502
20130.210.01
RESISTOR, METAL FILM, 1/8W, 1%,
2.10K, SMT
R112, R127
20130.348.01
RESISTOR, METAL FILM, 1/8W, 1%,
3.48K, SMT
R204, R210, R217, R220, R245,
R246, R279, R280, R281, R282,
R288, R290
20151.365.01 RESISTOR, 3.65K, 0.1%, SMT
R130, R133, R135, R136, R143,
R145, R147, R148
20123.499.01
RESISTOR, METAL FILM, 1/8W, 1%,
4.99K, SMT
R101, R103, R105, R108, R116,
R118, R121, R124
20130.562.01
RESISTOR, METAL FILM, 1/8W, 1%,
5.62K, SMT
R113, R128
20130.845.01
RESISTOR, METAL FILM, 1/8W, 1%,
8.45K, SMT
R201, R202, R205, R207, R208,
R211, R212, R214, R215, R218,
R267, R268, R270, R271, R273,
R274, R276, R277, R283, R285
RESISTOR, METAL FILM, 1/8W, 1%,
10K, SMT
R237
20124.100.01
RESISTOR, METAL FILM, 1/8W, 1%,
10.0K, SMT, RESISTOR, METAL
FILM, 1/8W, 1%, 10K, SMT
R102, R109, R110, R117, R122,
R125, R251, R252, R265, R293,
R296, R519, R527, R531
20124.100.01
(1206)
RESISTOR, METAL FILM, 1/8W, 1%,
10.0K, SMT
R532, R533
20511.310.01 POT, TRIM, 10K VR200, VR201, VR202, VR203
20121.100.01
RESISTOR, METAL FILM, 1/8W, 1%,
10OHM, SMT
R154, R200, R266
21319.610.01
(6032)
CAPACITOR, P, 20V, 10%, 10UF C520
