OPTIMOD-AM DIGITAL INSTALLATION
2-23
age modulation by equalizing your transmitter and/or antenna system with the
9400’s Transmitter Equalizer.
16. Complete Station ID (optional).
The Station ID is an optional setting that you can provide to associate the 9400
with the station providing the program material (e.g., “KABC”). The name can
be up to eight characters long. It is used to identify your 9400 to Orban’s 9400 PC
Remote application and appears on the Main Screen when the 9400 is being con-
trolled by the PC Remote application.
A) Navigate to S
ETUP > NEXT > TIME DATE AND ID > STATION ID.
B) Use the knob to set the each character in the ID. Use the N
EXT and PREV but-
tons to control the cursor position.
C) When finished entering your name, press the SAVE button. If you escape to
the main screen from Setup, you can now see the station name toggle on the
main screen.
The following material provides detailed instructions on how to set up the 9400. If
QUICK SETUP does not fully address your setup needs or if you wish to customize
your system beyond those provided with QUICK SETUP, then you may need the addi-
tional information in the sections below. However, for most users, this material is
only for reference because QUICK SETUP has enabled them to set up the 9400 cor-
rectly.
Analog and Digital I/O Setup
For the following adjustments, use the appropriately labeled soft button to choose
the parameter to be adjusted. To change a parameter (like an output level), it is
usually necessary to hold down the soft button while turning the knob.
1. Make sure that the transmitter is turned off.
This avoids potential damage caused by overdriving it. You will set the modula-
tion level later in this setup procedure.
2. Temporarily set the external AGC mode to “No.”
A) Navigate to S
ETUP > NEXT > NEXT > EXT AGC and set EXT AGC to NO.
If you are using a external AGC like the Orban 8200ST, you should restore
this setting to Y
ES after the setup procedure is complete.
3. Adjust Input selector.
A) Navigate to S
ETUP > IO CALIB > ANLG IN/DIG IN.
