- 38 -
ORUS RF Programmable Thermostat User Manual
■ Display indications
14) “Day” Field
15) “Programming mode” Field
16) “Environment temperature” Field
17) “Set program” Field
18) “Manual operation activation” Field
19) “Timer" Field
20) “Air conditioning activation” Field
21) “Heating activation” Field
22) “Clock” Field
23)
Not used Field
24) “Radio frequency transmission” Field
25) “Unit of measurement” Field
26) “Off” Field
14
24 19
16
26
22
21
20
18
15
25
17
23
