Ormazabal cgm.3-rc User Manual

IG-183-EN version 06; 31/03/2020
12
Description and main characteristics General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
cgm.3-rb
f
ekor.vpis / ekor.ivds voltage presence indicator
Figure 1.14. Mimic diagram of cgm.3-rb
cgm.3-rc / cgm.3-r2c
Figure 1.15. Mimic diagram of cgm.3-rc / -r2c cubicle
