ORTEC GEM30P4 - GEM Streamline and ICS Cryostat Configurations

GEM Series Coaxial HPGe Detector
Product Configuration Guide
19
GEM Streamline Cryostats
• Append matching Detector Endcap Size designation to cryostat model: -70, -76, -83, -95, -108 [e.g., CFG-SJ-95 for GEM75-95, or CFG-SL-XLB-76 for
G
EM25-76-XLB-C]
• Dewar required. Select dewar from GEM Streamline Dewars.
Model No. Description
CFG-GG Gamma Gage Cryostat
CFG-HJ J-type Cryostat with Remote Preamp. (for -HJ option only)
CFG-SD Down-Looking Cryostat
C
FG-SH Horizontal Cryostat (Dipstick type).
CFG-SJ J-type Cryostat
CFG-SL Side-Looking Cryostat
CFG-SV Vertical Cryostat (Dipstick type).
LOW-BACKGROUND
CFG-GG-LB Low-Background Gamma Gage Cryostat
CFG-HJ-LB Low-Background J-type Cryostat with Remote Preamp. (for -HJ option only)
CFG-SD-LB Low-Background Down-Looking Cryostat
CFG-SH-LB Low-Background Horizontal Cryostat (Dipstick type).
CFG-SJ-LB Low-Background J-type Cryostat
CFG-SL-LB Low-Background Side-Looking Cryostat
CFG-SV-LB Low-Background Vertical Cryostat (Dipstick type).
CFG-SD-XLB Extra-Low-Background Down-Looking Cryostat
CFG-SH-XLB Extra-Low-Background Horizontal Cryostat (Dipstick type).
CFG-SJ-XLB Extra-Low-Background J-type Cryostat
CFG-SL-XLB Extra-Low-Background Side-Looking Cryostat
CFG-SV-XLB Extra-Low-Background Vertical Cryostat (Dipstick type).
GEM ICS Cryostat
• May only be purchased with a detector.
• Append matching Detector Endcap Size designation to Cooling Rod Length model: -70, -76, -83, -95, -108 [e.g., CFG-ICS, ICS-LL102-70 for GEM25-ICS].
Model Description
CFG-ICS-E
CFG-ICS
Integrated Cryocooling System with External Preamp. Cooling Rod Length must be specified ,see below.
Cooling Rod Length. Add as separate line item ICS-LLExxx where xxx = one of the following lengths: 025, 031, 037, 050, 063, 075, 088,
101, 114, 126, 139, 152, 164, 177, 190, 202, 215, or 228 and append matching Detector Endcap Size [e.g., ICS-LLE101-70].
Integrated Cryocooling System with Internal Preamp. Cooling Rod Length must be specified ,see below.
Cooling Rod Length. Add as separate line item ICS-LLxxx where xxx = one of the following lengths: 051, 064, 076, 089, 102, 114, 127,
140, 152, 165, 178, 191, 203, 216, 229, 241, 254, 267, 279, 292, or 305 and append matching Detector Endcap Size [e.g., ICS-LL102-70].
