Ortovox 3+ User Manual

29 GB
QUICK GUIDE
PARTNER OR GROUP CHECK
PARTNER OR GROUP CHECK
(“The daily check”)
Switch the ORTOVOX 3+ to SEARCH
(= RECEPTION).
Now switch the 3+ on (1) and press
the MARKING BUTTON (8) simulta-
neously.
If the transmitter‘s parameters are
OK, then “00” is shown on the dis-
play. If no transmitter is located
within a circumference of 1 m from
the reception device, then “--” is
displayed.
Warnings about the tested transmit-
ter are displayed with E1 – E7.
WHAT THE WARNINGS MEAN
DURING THE PARTNER
CHECK
The warnings E1 to E7 signal that one
or more of the measured parameters
on the transmitter do not meet the
standard for avalanche transceivers.
If one of these warnings is shown,
then the transceiver must be sent to
the service department.
E1: Frequency
E2: Width of the transmission signal
E3: Frequency and width of the trans-
mission signal
E4: Transmission cycle
E5: Frequency and transmission
cycle
E6: Transmission cycle and width of
the transmission signal
E7: All tested parameters defective
1
8

Ortovox 3+ Specifications

General

Frequency	457 kHz
Number of Antennas	3
Marking Function	Yes
Multiple Burial Indication	Yes
Operating Temperature	-20°C to +45°C
Digital Search Strip Width	40 m
Waterproof	Yes
Battery Life	250 hours in send mode
Weight	210 grams (including battery)
