Ortovox 3+ - Operating Elements; Device Components Overview

24GB
OPERATING ELEMENTS
2
3
4
5
6
7
8
9
1
10
SLIDING SWITCH
(SEARCH MODE)
TRANSMISSION SWITCH
OVER (TRANSMISSION MODE)
DIRECTION ARROW
DISTANCE INDICATOR
BATTERY CAPACITY
NUMBER OF SIGNALS
MARKING BUTTON
LOUDSPEAKER
ON/OFF SWITCH,
BATTERY COMPARTMENT
LOCKING SLIDE
Subject to changes (08/ 2010)
The back of the carrier bag
contains an extra compartment
for storing the 3+ and carrying
straps.
