- 21 -
EN
INSTALLATION OF THE CHILD CAR SEAT
1) Group 0+ (rearward facing)
(For children from 0-13 kg)
1
2
• Press both side Isox connector buttons to
extend the Isox connectors in length.
• Insert the Isox connectors into the insertion
aids and press until they click into place.
• The display on both sides only turns green
when the connections are made. Pull the
child car seat towards the backrest until it
stands securely.
• Put the car seat into maximum reclining
position
• Rotate the seat into rearward facing position
• Take the Top-Tether out of the pocket.
• To release the Top-Tether, press the grey
adjustment button with one hand and pull
the side of the belt anchor to the required
length with the other hand.
• Pull the upper belt through the belt guide
marked blue on the seat.
• Attach the anchor to the attachment point
on the rear of the car seat.
• Tighten the top tether by pulling on the
other side of the strap. Make sure the indi-
cator is green.
