- 23 -
3) Group 1 (forward facing)
(For children from 9-18 kg)
1
• Place the child car seat on the car seat and
rotate it to the forward facing position.
• Press both side Isox connector buttons to
extend the Isox connectors in length.
• Insert the Isox connectors into the insertion
aids and press until you hear them click into
place.
• The display on both sides only turns green
when the connections are made. Press the
child car seat against the backrest until it is
secure.
EN
2
• Take the Top-Tether out of the pocket.
• To release the Top-Tether, press the grey
adjustment button with one hand and pull
the side of the belt anchor to the required
length with the other hand.
• Pull the Top-Tether to behind the backseat
where the Top-Tether anchor is positioned
• Attach the anchor to the attachment point
on the rear of the car seat.
• Tighten the top tether by pulling on the
other side of the strap. Make sure the indi-
cator is green.
