10 of 20
Fig. 9: wristband battery housing
Batteries are fitted into the wristband battery housing and
secured by the holding catch at the wrist side of the wrist-
band. Release the holding catch to remove the battery.
The batteries provided are designed to work
specifically with the Touch Bionics i-digits™
wristband and are not to be used with any
other device.
Only Touch Bionics batteries are approved
for use with i-digits™, use of alternative bat-
teries will invalidate the warranty.
Charging time from full discharge is approximately 2 hours.
i-limb
®
Power Pack batteries for i-digits™ should only be
charged using the Touch Bionics battery charger (fig.7)
supplied. Place the batteries in the charger as illustrated.
Insert the charger lead from the mains charger into the
charger base unit. Insert the mains charger into the power
outlet (fig.10).
On the base plate of the charger base unit you will see the
various light sequences:
• Middle light on: Charger is plugged in
• 2nd and 5th lights blinking Green: Batteries are
charging
• 2nd and 5th lights solid Green: Batteries are charged
• 1st and 4th Red lights on: Battery fault, unplug and
try again. If lights continue to illuminate, contact your
clinical team.
Fig. 10: charger base unit
Do not pull cable to remove the lead.
Switch the device OFF to preserve battery
power when not in use.
Replace the battery annually for optimal
performance.
To ensure i-digits is continually functional,
charge at the end of each day.
