1.2 Using this Manual
This manual contains all of the information that you need to connect, calibrate, operate
and maintain the STATUS 18R console.
When learning to operate the console, it is recommended that you review Section 3 to
familiarize yourself with control and indicator terminology before moving on to Section 4,
Operation and Section 5, Eagle Automation.
Appendix, contains an LCD Menu Reference that describes all of the LCD Menus. Refer
to this for a capsule description of what each LCD selection button does.
1.2.1 Section Descriptions
Section 2 - Installation: This section contains connector pinouts and instructions for
unpacking and identifying the equipment shipped with the console. Guidelines and
recommendations for installing and interfacing the console are also included.
Section 3 - Controls and Indicators: Section 3 identifies each control and indicator of
the STATUS 18R console. A brief description of each item and it’s function is included.
Section 4 - Operation: This section describes the operation of the console and gives
step-by-step examples of how various tasks are accomplished.
Section 5 - Eagle Automation: Section 5 covers all aspects of Eagle Automation from
Fader modes to offline utilities. The Quick Tour section takes you through a simple mix
session using Eagle Automation.
Section 6 - Alignment and Maintenance: This section contains information for
installing software and setting up the console. Instructions for using the CompuCal
system to align the internal levels and meters is also included.
Appendices: The Appendices contains additional reference material for operating the
STATUS 18R.
1.2.2 Terminology
I/O modules on the STATUS 18R incorporate a Channel Path (CHAN) and a Mix Path
(MIX). This can cause confusion when referring to the Channel Path on a given “Channel”
of the console. The terms “Track” and “Group” have a similar problem. When used
alone, the words “Track”, “Group” and “Channel” should read in context of the section
they are used in.
Where possible the following convention will be used when referring to Channels, Tracks
and Groups:
• Channel: Used by itself, Channel usually refers to a single audio path on a console or
tape machine.
• Path: A Path refers the route that a signal follows through the Input Module. This could
be the Channel or Mix Path.
• Channel or Chan Path: Refers to the signal path on an I/O module that is normally
used for assigning to the Track Outputs. This path is controlled by the upper fader and
is color coded Light Green.
• Mix Path: Refers to the signal path on an I/O module that is normally used for mixing
because it is closest to the engineer. This path is controlled by the lower fader and is
color coded Violet.
1 - 2
August 1999
Section 1 Introduction STATUS 18R Operation and Maintenance Manual
