Parts List & Operating Instructions Form No. 102737
Hydraulic Unit
If the hydraulic unit needs service, it can be removed easily for repair or
shipment to a manufacturer-approved service center. If the unit is
shipped, remove the platform assembly and handle to minimize package
size and weight. The hydraulic unit will separate from the jack by
removing the gland nut.
Refer to any operating instructions included with the product for detailed information about
operation, testing, disassembly, reassembly, and preventive maintenance.
Items found in this parts list have been carefully tested and selected by OTC. Therefore: Use
only OTC replacement parts!
Additional questions can be directed to the OTC Technical Services Department.
Gland Nut
Hydraulic Unit Detail
65,66 63 62 61 60 59 64
85 84 83 82 81 85 80 79 78 77 76 74,75 73 72 71 70 69 68 67
To Next Page
