OTC 1728 - Page 7

Parts List & Operating Instructions Form No. 102737
Description
Item
No.
Part
No.
No.
Req'd
46 1728-46 1 Side Tilt Shaft
47 1728-47 2 Tilt Trunnion
48 1728-48 1 Pivot Bracket
49 1728-49 4 Cap Screw (3/8" x 1)
50 1728-50 4 Lockwasher (3/8")
51 1728-51 1 Hydraulic Unit Bracket
52 1728-52 1 Long Tilt Shaft
53 1728-53 1 Crank (lower)
54 1728-54 1 Tow Handle
55 1728-55 4 Hex Jam Nut (1/2")
56 1728-56 4 Lockwasher (1/2")
57 1728-57 4 Self-locking Cap Screw (3/4" long)
59
4
1728-59 1 Jam Nut (3/4"-l 6 UNF)
60
4
1728-60 1 Rim Washer
61 1728-61 1 Swivel Pivot
62
4
1728-62 1 Pump Sleeve
63
4ju
1728-63 1 Seal (13/16" OD x 7/16" ID x 1/4" deep)
64
4j
1728-64 1 Plunger Weldment
65 1728-65 1 Soc. Hd. Cap Screw (5/16"-18 UNC)
66 1728-66 1 Metallic Gasket
67 1728-67 1 Ram Guide
68
u
1728-68 1 O-ring (1" OD x 3/16" ID x 3/32" dia.)
69 1728-69 1Cap
70
u
1728-70 1 Seal (11/16" OD x 7/16" ID x 3/16" deep)
71 1728-71 1 Magnet
72 1728-72 1 Spacer
(for serial no. 83-225639 and below; not needed for
serial no. 83-225640 and above)
73 1728-73 1 Suction Tube (22-5/8" long)
74
u
1728-74 1 Felt Packing Gasket
75 1728-75 1 Packing Gland (2" bore;
for serial no. 83-225639 and below)
507532 1 Packing Gland (2" bore; for serial no. 83-225640 and above)
76 1728-76 1 Ram
77 1728-77 1 Suction Tube (6" long)
78 1728-78 1 Cylinder Tube
79 1728-79 1 Reservoir Tube
80 1728-80 1 Release Knob Sub-assembly
81 1728-81 1 Compression Spring (.406 OD)
82 1728-82 1 Ball (3/8" dia. RC)
83 1728-83 1 Compression Spring (.250 OD)
84 1728-84 1 Ball (1/4" dia. RC)
85 1728-85 2 Plug w/ o-ring
Available Kits
221089 1 Two-piece Plunger Kit (items marked with
j)
221088 1 Complete Plunger Kit (items marked with
4 )
221090 1 Soft Seal Kit (3") (items marked with u)
525797 1 Head Assembly
