This document outlines the assembly and features of the Otto Wilde Storage Modules, designed to complement the S16, S24, and S32 grill platforms. These modules provide versatile storage and expansion options for an outdoor kitchen, emphasizing high-quality construction and user-friendly design.

Function Description:

The Otto Wilde Storage Modules serve as an integral part of an outdoor kitchen system, offering organized storage for grilling accessories and providing additional counter space for meal preparation. The modular design allows for customization, enabling users to choose between a full cabinet or a set of drawers to suit their specific storage needs. These modules are built to withstand outdoor conditions, ensuring durability and longevity. They integrate seamlessly with the Otto Wilde grill platforms, creating a cohesive and functional outdoor cooking environment. The system is designed for both mobile and stationary use, with options for adjustable casters or fixed installation. Specific modules are available to accommodate a cooktop (C16) or a sink (S32 Sink), further enhancing the functionality of the outdoor kitchen. The design incorporates soft-close hinges for smooth operation and a premium feel.

Important Technical Specifications:

The storage modules are constructed from 100% stainless steel, ensuring resistance to corrosion and the elements, making them ideal for outdoor use. The assembly process involves various screws of different sizes:

M5x12 Screws (A): 32 pieces for general assembly.
M6x16 Screws (C): 16 pieces for specific structural connections.
M5x10 Screws (D): 4 pieces for particular components.
M4x8 Screws (B): 2 pieces for the S32+ module.
Module Connector Screws (G): 4 pieces for connecting modules.

The package includes essential components for the basic module:

1x Base Plate
1x Back Wall
1x Right Side Wall
1x Left Side Wall

Additional components for enhanced functionality include:

1x Rubber Protect Ring
1x Cross Brace Top
1x Cross Brace
4x Adjustable Castors (for mobility)
1x Base Closure
1x Counter Top (Arbeitsplatte)
1x Toeboard Left
1x Toeboard Right
1x Toeboard Front
1x Toeboard Back
1x Gas Bottle Basket (for gas bottle storage)

For the S32+ module, specific parts are provided:

1x Center Panel S32
1x Cross Brace S32

The C16 Cooktop module includes:

1x Cooktop
1x Cooktop Cover
1x Gas Hose
2x Ring Screws
2x Hose Clamps
1x Water Drain Hose

The S32 Sink module includes:

1x Sink
1x Faucet
1x Siphon (compatible with DN 50 pipes for vertical installation)
1x Front Cover 32"
1x Small Cover
1x Large Cover
1x Angle Valve
1x Front Mount Set

Usage Features:

The Otto Wilde Storage Modules are designed for ease of use and customization.

Modular System: The platform is based on a modular system, allowing users to expand their G32 grill setup with additional modules at any time. This flexibility ensures that the outdoor kitchen can adapt to evolving needs and preferences.
Storage Options: Users can choose between a cabinet for larger items or a set of drawers for smaller accessories, providing tailored storage solutions.
Countertop: The spacious stainless steel countertop offers a durable and easy-to-clean surface for meal preparation.
Mobility vs. Stationary: The inclusion of adjustable castors allows for easy repositioning of the modules, while options for fixed installation cater to a more permanent setup.
Integrated Appliances: The modules are designed to integrate specific appliances like the C16 Cooktop and the S32 Sink, transforming the storage unit into a fully functional cooking and cleaning station.
Gas Bottle Storage: A dedicated gas bottle basket is available for safe and convenient storage of gas cylinders, particularly useful for the C16 Cooktop.
Soft-Close Hinges: The soft-close hinges on doors and drawers (if applicable) ensure quiet and smooth operation, enhancing the user experience.

Maintenance Features:

The stainless steel construction is a key maintenance feature, as it is inherently resistant to rust and easy to clean.

Easy Cleaning: The stainless steel surfaces, including the countertop, can be easily wiped clean, making maintenance simple and quick.
Durable Materials: The 100% stainless steel construction ensures the modules withstand outdoor weather conditions and resist corrosion, reducing the need for frequent repairs or replacements.
Assembly Instructions: The detailed assembly instructions, including visual guides and tool requirements, facilitate proper setup, which is crucial for the longevity and performance of the modules. The instructions emphasize starting screws by hand and then tightening with the provided tools to prevent damage.
Component Replacement: The modular nature suggests that individual components could potentially be replaced if damaged, extending the lifespan of the entire system.
Protective Elements: The inclusion of a rubber protect ring indicates attention to detail in protecting components and potentially reducing wear and tear.
