1) Insert the fly pole (C) through the sleeve
found at the edge of the fly awning, over
the front door.
2) Flex the pole and insert each end into the
pin located on either side of the door at
side pole.
3) Wrap the Velcro
® fasteners, sewn on the
underside of the fly, around the
fibreglass tent poles.
Step 11: Packing the tentStep 10: Disassembly
1) To take down the tent, disassemble in
reverse order.
2) Remove accessories (if included).
3) Remove and fold fly.
4) Be sure to leave doors and windows
unzipped to avoid zipper damage.
5) Remove stakes with hammers or stake
puller. DO NOT pull on tent.
6) Carefully disengage poles from pins. Push
poles away from you through the sleeves
to minimize risk of damage to tent or poles.
7) Keep poles and stakes together in bags
provided.
1) Spread tent flat, distribute evenly.
2) Fold into quarters not to exceed the length
of pole bag.
3) Lay pole bag at opposite end from door.
Tightly roll bag and skin and fly forcing air
through unzipped door.
4) Secure with ties and place in carry bag with
stakes and accessories.
5) Tent must be clean and dry before storage.
Store off concrete floor.
Be certain campfires are extinguished.
Dispose of trash appropriately.
Dimension A should
be close to but not
exceed the length
of the pole bag.
A
Fold tent into a
rectangular shape.
Front of tent
(door unzipped)
Step 8: Secure fly pole and fasten the fly
Tent appears as shown.
Step 6: Stake tent
Step 9: Secure guy lines
1) Secure tent using all guy lines and stakes.
Tent must be secured for proper function.
Step 5: Raise tent using the easy set-up handle
1) Locate the easy set-up handle at the left end of the tent. Pull the handle in a slow and
steady manner to extend the tent floor.
1) Stake down the tent by inserting a stake
through the remaining stake loops, located
along the perimeter of the tent.
2) Make certain the tent floor is pulled out
evenly and tightly.
3) Hammer the stakes into the ground
at a
45
0
angle using a hammer or mallet.
Step 7: Attach fly
1) Unfold the fly and stretch out all corners.
2) Place the fly over the tent, making certain
the fly awning is over the front door.
3) Attach the fly to the tent by hooking the
plastic s-hooks on the fly corners to the
metal o-rings at the tent corners.
