OUTDO PC-2000 - Operating Principle; AC Pure Sine Wave Output

8
7
OPERATING PRINCIPLE
220Ｖ
0Ｖ
－220Ｖ
LCD display panel, button of Master
Control Panel (MCP)
High capacity lithium
ion battery
Specialized DC 5V 12V for lithium ion battery,
AC outlet main-board
DC 5V 3A output DC 12V 3A output AC sine wave output
AC PURE SINE WAVE OUTPUT
Main-control
CPU
UPS
