8
Insert 2 small bolts (B) through the small bracket (Part 8) eyelets, center
leg support and short leg eyelets. Screw them all together with the nuts (C)
facing towards the footsteps.
8
C
8
B
B
2 Small Bolts
Small Bracket
2 Nuts
B
8
W K
C
C
9
Insert 4 small bolts (B) through the large bracket (Part 9) eyelets, center leg
support and the longest end of the handlebar eyelets. Screw all of the pieces
together with the nuts (C) provided. Make sure the nuts are facing inwards.
Use the allen key (K) and the wrench (W)
to tighten the bolts and nuts.
Use the allen key (K) and the wrench (W)
to tighten the bolts and nuts.
4 Small Bolts
2 Large Brackets
4 Nuts
B
9
W K
C
9
9
B
C
C
B
To Next Page
