1 Vents
The thermal vents are designed to cool the internal
components and avoid overheating.
2 HDD / RAM / SSD / WLAN Compartment Cover Screws
You can remove the screws to install or remove the HDD /
RAM / SSD / WLAN compartment cover. ( Please refer to the
HDD / RAM / SSD / WLAN compartment view on the
following page.)
3 Speakers
Bottom View
The product’s thermal vent will depend upon the
actual shipping product.
1
2
3
18
