OWC Mercury On-The-Go User Manual

OWC Mercury On-The-Go SATA
Assembly Addendum
On page 8 and 9 of the OWC Mercury On-The-Go Assembly Manual,
there is a procedure change necessary. Instead of attaching the hard
drive to the rewire bridge card as the manual shows, you now need
to attach the hard drive to the heatsink and not attach the drive to the
bridge card.
Remove the 2 screws securing the heatsink into the acrylic enclosure.
Gently slide the heatsink out of the acrylic enclosure.

OWC Mercury On-The-Go Specifications

General

Storage drive size	2.5 \
Maximum storage capacity	2.2 TB
Number of storage drives supported	1
Supported storage drive interfaces	Serial ATA
FireWire 800	Yes
Product color	Transparent
Chipset	Oxford 944, ASMedia 1051e
Data transfer rate	5 Gbit/s
Cables included	FireWire, USB

Weight and Dimensions

Depth	139.7 mm
Width	88.9 mm
Height	25.4 mm
Weight	190 g
