OXO Multibeam - Manual Mode Operations; Fixed Color Mode; Program Regulation; Single Color Luminance Adjust

4 5
Table 4
DMX MODE 4
CH1 CH2 CH3 CH4 CH5
R G B W Dimmer
0 - 12 = OFF
1 - 255 dim > light
Table 5
DMX MODE 5
CH1 CH2 CH3 CH4 CH5 CH6 CH7
R G B W Color Macro Value Strobe Dimmer
See macro mode 1 - 255 slow > fast 1 - 255 = dim > light
0 = OFF 0 = OFF 0 = OFF 0 = OFF
1 - 255 dim > light
Table 6
DMX MODE 6
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
R G B W Macro mode Strobe / speed mode Total dimmer
0 1 - 12 (OFF)
Strobe 0 - 15 :
static
16 - 255 : 16 steps
color regulation
(Macro mode)
NA
Speed
Regulation
0 - 255 : 16 steps
auto mix-color
3 colors jump
7 colors jump
0 - 255 = NA program sound
control
1 - 255 dim > light
0 - 255 dim > light
1 - 255
(0 - 127)
(128 - 159)
(160 - 191)
(192 - 223)
(224 - 255)
MODE LCD DISPLAY OPERATION
Turn on display
OXO V1.0
When turn on the unit, it will display OXO V1.0
Edit name
Edit
Company
Edit Company : when pressing the second key or the third one; you can edit, you can
choose “ A, B, C, ……..Z, ” ” via the first key; you can clear word via the second key ;
and when you want to move right, you can use the third key ;
final you can save what you edit via moving right the third key until the lcd display
“ saving……”
LCD DISPLAY
On all the time DispPerm On / Off
LCD is on all the time; by pressing the second key or the third key, you can toggle
between DispPerm On and DispPerm Off
Auto turn off
DispPerm
Off
LCD can turn off automatically after running 10s..Any button is no function under
this mode. It can display by pressing any button 3s.
DMX MODE
CH 1 DMX -1CH DMX** ***--DMXaddress (1~512) CH1 (macro) detail see table 1
CH 2 DMX -2CH DMX** ***--DMXaddress (1~512) CH1 (macro)) / CH2 (dimmer) detail see table 2
CH 4
DMX -4CH
DMX ***
***--DMXaddress (1~512) CH1 (R) / CH2 (G) / CH3 (B ) / CH4 (W)
detail see table 3
CH 5
DMX-5CH
DMX ***
***--DMXaddress (1~512) detail see table 4
CH1 (R) / CH2 (G) / CH3 (B ) / CH4 (W) / CH5 (dimmer)
CH 7
DMX-7CH
DMX ***
***--DMXaddress (1~512) detail see table 5
CH1 (R) / CH2 (G) / CH3 (B ) / CH4 (W) / CH5 (macro) / CH6 (strobe speed) / CH7
(dimmer)
CH 8
DMX-8CH
DMX ***
***--DMXaddress (1~512) CH1 (R) / CH2 (G) / CH3 (B) /
CH4(W) / CH5(macro) / CH6(speed) / CH7(mode) / CH8(dimmer) detail see table 6
MANUAL MODE
Fixed color mode ColMacro Macro ** **- 32 kinds of colors (0~32) 32 kinds of macro mode + black
Program
regulation
mode ColProgr Progr **
**-- preset 9 kinds programs (1~9) + ALL (all programs)
Change preset 9 kinds of programs via Up / Down key
speed ColSpeed Speed **
**-- program speed choose 1~16, so (16 : fastest speed, so : sound control program
Change the program speed and sound control via Up / Down key
Single
Color
luminane
adjust
R
ColSet
G
Red ***
Green ***
Blue ***
White ***
B
ColSet
ColSet
W
ColSet
Figure 1
Macro mode
MACRO R G B
Black 0 0 0
Macro mode 1
Macro mode 2
Macro mode 3
Macro mode 4
Macro mode 5
Macro mode 6
Macro mode 7
Macro mode 8
Macro mode 9
Macro mode 10
Macro mode 12
Macro mode 14
Macro mode 15
Macro mode 11
Macro mode 16
Macro mode 13
MACRO R G B
***--R adjust static luminance (0 ~ 255)
Change luminance value via Up / Down key (0 off, 255 light)
***--G adjust static luminance (0 ~ 255)
Change luminance value via Up / Down key (0 off, 255 light)
***--B adjust static luminance (0 ~ 255)
Change luminance value via Up / Down key (0 off, 255 light)
***--W adjust static luminance (0 ~ 255)
Change luminance value via Up / Down key (0 off, 255 light)
Table 3
DMX MODE 3
CH1 CH2 CH4
R G W
0 - 12 = OFF
1 - 255 dim > light
CH3
B
Table 1 Table 2
DMX MODE 1
CH 1
Color Macro Value
See macro mode
0 - 12 = OFF
DMX MODE 2
CH 1 CH 2
Color Macro Value Dimmer
See macro mode 1 - 255 dim > light
0 = OFF0 - 12 = OFF
Macro mode 17
Macro mode 18
Macro mode 19
Macro mode 20
Macro mode 21
Macro mode 22
Macro mode 23
Macro mode 24
Macro mode 25
Macro mode 26
Macro mode 28
Macro mode 30
Macro mode 31
Macro mode 27
Macro mode 32
Macro mode 29
255
254
254
254
254
176
96
234
224
175
119
147
88
0
52
0
206 143 1 134 201
177 153 0 145 212
192 138 0 121 192
165 98 0 129 184
121 0 0 83 115
17 0 0 97 166
0 11 1 100 167
139 171 0 40 86
5 97 209 219 182
77 173 42 165 85
130 199 0 46 35
164 212 8 107 222
2 163 107 156 231
142 208 0 0 189
148 209 255 255 255
38 86 165 198 247
