General Guidelines:
• Materials are heavy and bulky minimum of 2 people are required for most installations
• Brace and tie off large beams and posts until all connections are made
• Wear proper safety equipment
• Check with local authorities and home owners association before construction
• Check for underground and or hidden utilities that could be damaged
• Be sure to use the right tool for the job
• Plan ahead and have the required hardware, fasteners and tools close at hand before starting the
installation
Steps:
1. Locate the tabs of the Truss Accent with the truss plate
2. Remove threaded covers from all Hex Cap Nuts
3. Insert Lag Bolts (sold separately) into Cap Nuts
4. OWT Lag Bolts require a 3/8” Hex Bit
5. Install the lag bolts
6. Replace Threaded Covers until ush with edge of the nut
7. HINT: Use tread lock on Threaded Covers in accessible areas
Note: Truss Accents are intended to be used in conjunction
with OWT Truss Plates. Use in any other manner is not recommended.
Use and Care: This hardware may not be suitable for every situation or installation application. A
design professional should be consulted to ensure the specic installation application meets local
building code requirements.
If hardware becomes dirty clean with soap and water. Avoid abrasions to surface and touch up any
scrapes with paint. Rinse with fresh water if hardware comes in contact with ice salt or salt water.
Truss Accent Item #: 56616
LaredoSunset-InstallationGuide
TheNumberofTrussAccentKitsRequiredIsIndicatedByTheNumberNextToThisIcon:
45° Flush Inside
Item #: 56611
90° Flush Inside
Item #: 56615
90° Flush Outside
Item #: 56614
Butt Joint
Item #: 56613
“T″TiePlate
Item #: 56612
Truss Base Fan – 8:12
Item #: 56619
Truss Base Fan – 10:12
Item #: 56620
CorrespondingProducts
To Next Page
