PAB MP1 Standard - Type II Lamp Holder Mounting; Adjusting Lamp Angle

23
Type II lamp holder (tightening lamp holder)
2
To adjust the lamp angle, turn the
lamp clockwise or counter clockwise
1
First mount the lamp holder: slide
the provided lamp holder from the
top to the bottom of the lamp holder
adapter positioned on the sides of the
helmet. Make sure the lamp holder
is rmly placed and positioned as
shown in the picture.
2
Mount the lamp: slide the lamp into
the lamp holder from the front of the
lamp holder (UK 4AA or 2AA) and then
tighten the screw on the top of the
lamp holder to secure the lamp.
Picture 26
Picture 25
