UMA
SURFACE MOUNT OPTION
UMA CAN BE BOLTED TO A SURFACE
USING THE PROVIDED SCREW.
TO SECURE UMA TO A SURFACE:
CONTACT MANUFACTURER FOR BOLT
DRILL A 5/16TH INCH (8 MM) HOLE
THROUGH SURFACE OF TABLE
ADD LOCK WASHER AND THREAD NUTS
ONTO BOLT FROM BELOW. TIGHTEN
UNTIL SECURE; DO NOT OVERTIGHTEN.
MAX TABLE
THICKNESS
1.25 INCHES
(32 MM)
THREAD SHORT END OF PROVIDED
BOLT INTO THREADED HOLE ON
UMA BASE UNTIL FLANGE IS FLUSH.
DO NOT OVERTIGHTEN
INSTALL LONG END OF PROVIDED
BOLT THROUGH TABLE
pg. 08
