- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1. Remove blade locking bolt (reverse threaded).
2. Position new 300 mm abrasive cut-off wheel into position.
Use only certified abrasive cut-off wheels.
3. Gently tighten blade locking bolt (Note: locking bolt is reverse
threaded).
4.4 Changing abrasive cut-off wheels
14
!
Changing Blade
Remove: Loosen by
turning clockwise
Tighten: Turn counter-
clockwise
To prevent
shaft from
turning, push
in locking rod
to hold in place
