MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Mechanical-motor
M3-SH
MEGA-T300 Blade shroud
T3-M-001
Arbor bolt
T3-M-002
Arbor inside flange
T3-M-003
Arbor blade outside flange
T3-M-004-1
Flange-lock-housing
T3-M-004-2
Flange lock nut
T3-M-004-3
Flange lock shaft
25
