MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Mechanical-Hood
T3-M-034
Cooling sheet top panel
T3-M-052 Electrical panel base plate
T3-M-053 Electrical panel support box
T3-M-035
Back sheet
T3-M-036
Cooling back panel
T3-M-037
Side cooling vent
