MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Plumbing
M3-D
MEGA-T300 Drain hose (40 mm) - 1.5m
M3-H
MEGA-T300 Coolant line (20 mm) - 1.5 meter
M3-COOL
MEGA-T300 Flexible coolant line (pair) (Part
No. M3-COOL)
MEG-RHV
Rinse hose and valve
MEG-RH
Rinse hose
M2-NOZ
Rinse hose nozzle
M2-NOZ-T
Rinse hose nozzle tip
