- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1.2 Technical Specifications
Electrical specifications: 208Y (phase-phase or 120/120/120 to
ground), 380V, 400, 480V 3-phase
optional)
Motor power: 4.5 hp (3 kW) - 3-phase to ground
Cut-off wheels: 300 mm (~12-inch) diameter
Wheel arbor: 32 mm (~1.25 inch) diameter
Maximum sample diameter: 4-inch (100 mm)
Weight: Approx. 350 lbs (160 kg)
Dimensions (WxHxD): Approx. 36” x 34” x 26” (hood closed)
(90 cm x 86 cm x 65 cm)
Approx. 36” x 34” x 32” (hood open)
(90 cm x 86 cm x 82 cm)
Table dimensions (WxD): 12” x 9”
(300 mm x 230 mm)
Cutting chamber: Cast aluminum block construction
Hood and body Fabricated steel with shock resistant
plastic window
Working temperature: 32° - 100°F (0 - 40°C)
Shipping temperature: 32° - 100°F (0 - 40°C)
Storage temperature: 32° - 100°F (0 - 40°C)
Recirculation system (included): 15 gallons (60 liters)
3
EU Directives: Machinery directive 2006/42/EC
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility directive 2004/108/EC
EU Harmonized Standards: EN ISO 1200:2010
EN 61010-1:2010
EN 61326-1:2006
