1. To Attach the Front & Rear Stabilizers
Spring Washer M8х2.0t—4 PCS (97)
Washer 20х9х2.0t—4 PCS (8)
M8 Acorn Nut—4 PCS (7)
Bolt M8х56
STEP 1A: As shown to the Right, attach
the Front Stabilizer (59) to the Frame with
bolt (9), washer (8), lock washer(97), and
acorn nut (7) then tighten the nut with the
included wrench (79) or a 13mm wrench or
socket.
Note: The front Stabilizer (59) has the
wheels on it, AND the wheels must be
towards the front.
8
