Main parts and functions:
Element
Description
Function
1
Ice water reservoir
Insulated vessel to hold the ice water.
2
Insulated cover
Insulated cover for the ice water reservoir.
3
Electrical enclosure
Control system PIB.
4
Ice water pump
Supply the ice water to the cooling
application.
5
Cooling unit
Provide the required cooling capacity to the
evaporator.
6
Ice water
homogenisation
(PIB 25 370)
Ensure an even ice meltdown by injecting
air through the ice water reservoir.
The air blower is automatically
turned on when the ice water pump
is running.
7
Leg
Adjustment/levelling of the PIB
8
Evaporator
Cool / freeze the water in the ice water
reservoir.
9
Return header
Distribute the return (heated) water back
into the PIB.
10
Electronic ice thickness
sensors
Control the thickness of the ice layer
between the pre-set minimum and
maximum value.
11
Automatic ice water
level control
Maintains the ice water up the required
level.
12
Heat exchanger
(optional)
The heat exchanger provides cooling to a
secondary circuit and is available in the
following sizes:
- Type B28*46 (flow rate = 40l/min)
- Type B28*80 (flow rate = 60 l/min)
- Type B28*126 (flow rate = 100 l/min)
Type B28*126 is not possible with
PIB-8 and PIB-13
