Charging status indicator

The LEDs on the device light up and flash in different patterns, thus displaying the different

charging levels.

Below you can see the table of flashing patterns.

• = permanently luminous, ☼ = flashing, — = no light/blinking

Power

Light

Charging level

LED

Fault

LED

Display

Off

—

●

—

0.0

Stage 1. Desulfatation

●

☼ / ●

—

Output

Stage 2. Soft Start

●

☼ / ●

—

Stage 3. Main charge

●

☼ / ●

—

Stage 4. Remaining charge

●

☼ / ●

—

Stage 5. Battery test

●

☼ / ●

—

Stage 6. Reconditioning

●

☼ / ●

—

Stage 7. Preservation charge

●

☼ / ●

—

Fully charged

●

—

Stage 8. Maintenance charge

●

☼ / ●

—

Protection in case of missing

battery connection

●

—

0.0

Short-circuit protection

●

—

Reverse polarity protection

●

—

Shutdown protection

☼

—

Surge protection

●

—

●

- U -

Strong sulfation

●

☼

(LED level 1)

●

Battery

Volts

Charging not possible

●

☼

(LED level 2)

●

Defective battery

●

☼

(LED level 3)

●

Battery fully charged

●

(All LEDs)

—

Overheat protection

●

—

☼

- t -
