3. PadBot P2 InstallationBody Installation
1) Screw Body Fixer up to fix robot body, and follow correct direction to connect Body line with Base port.
 

 
2) Use screw key to fix M6 screw, and cover it with offered black plastic part.

Black bulge is
marked in red
Notch
