Zebra
You can switch between the zebra display and marker display.
Touch .
Each time the icon is selected, the indication changes in the following order:
Zebra 1 # Zebra 2
*
# Marker
*
# setting canceled
* It is not displayed when the [ZEBRA DETECT 2]/[MARKER] is set to [OFF]. (l 130)
≥ You can also use this function with a USER button. (l 78)
Zebra display:
Parts where white saturation (color saturation) is likely to occur (extremely brightly lit or shiny parts)
are displayed with diagonal lines (zebra pattern A).
Marker display:
Displays the luminance level of the center of the screen (luminance display frame B) in %.
It makes the adjustment of the brightness of the object easier, by checking the luminance level of
the object, when recording same object in different surroundings.
≥ Luminance level C is displayed between 0% and 99%. It will be displayed as 99% when it is
over 99%.
≥ This item cannot be set during Freeze Frame. (l 71)
≥ You can record an image with little white saturation if you manually adjust the shutter speed or
brightness not to display zebra pattern. (l 53, 57)
≥ The zebra pattern does not appear on the images actually recorded.
≥ It is also possible to adjust the level of the zebra pattern to be displayed. (l 130)
≥
It is also possible to change the [ZEBRA MODE] setting to change the display time for the zebra
pattern display.
(l 122)
(When Zebra 1 is set) (When Marker is set)
99%
