Specifications
[General]
Operation ambient temperature:
0 °C - 40 °C (32 °F to 104 °F)
Storage temperature:
-20 °C - 60 °C (-4 °F to 140 °F)
Operation ambient humidity:
10 % - 85 % (relative humidity)
Weight:
Main unit approx. 1.3 kg
(approx. 2.9 lb)
Battery plate approx. 150 g
(approx. 0.3 lb)
External dimensions (width
°
height
°
depth):
159 mm ° 146 mm ° 105 mm
(6.3 inches ° 5.7 inches ° 4.1 inches)
(Excluding protrusions)
[Power Supply Unit]
DC IN 24 V:
Round 5 pin
DC 24 V, maximum 4 A
BATTERY IN:
Rectangular 2 pin
DC 12 V (DC 11 V - 17 V), maximum 6 A
DC OUT:
Rectangular 2 pin
DC 13 V (DC 11 V - 17 V), maximum 5 A
[Transfer Unit]
DC power supply transfer
(AG-BS300P/E > this unit):
Maximum 100 m
(When using conductor cross-section area of
3.5 mm
2
or larger)
Signal transfer (AG-BS300P/E <> this unit):
Maximum 100 m
(When using the 5C-FW BNC cable)
[Analog Signal Output Unit]
RET OUT:
BNC
VBS, 1 V [P-P], 75 h
GENLOCK OUT:
BNC
SD SYNC, 75 h
3-value SYNC, 0.6 V [P-P], 75 h
[Digital Signal Input Unit]
SDI IN:
BNC, 0.8 V [P-P], 75 h
For HD SDI, compliant to SMPTE292M/
299M Standard
For SD SDI, compliant to SMPTE259M-C/
272M-A/ITU-R.BT656-4 standards
BS IN:
BNC, 75 h
[Digital Signal Output Unit]
BS OUT:
BNC, 75 h
[Control Unit]
REMOTE:
Round 10 pin
RET CTRL:
Round 6 pin
[External Device Connection Unit]
VF OUT:
D-Sub 15 pin
[Intercom Unit]
INCOM:
XLR 5 pin
[Supplied Accessories]
VF cable
Remote cable
Cable strap
Battery plate
Ferrite core
Weight and dimensions when shown are
approximately.
Specifications are subject to change without notice.
Input: DC 24 V, 4 A
DC 12 V, 6 A
Output: DC 13 V, 5 A
indicates safety information.
