Editing
77
Connecting external units
Headphones
External microphone
Microphone holder
Microphone
holder adapter
6 mm
12 mm
• When attaching an external microphone to the microphone shoe, use the supplied microphone holder
and microphone holder adapter.
• When attaching the microphone holder and the microphone holder adapter, be sure to tighten the screws
firmly even though you might hear a squeaking sound.
Stereo Microphone (optional)
AG-MC200G
INPUT1 or
INPUT2
3.5-mm stereo
mini jack
• Sound is no longer heard from the speaker when the headphones are connected.
To Next Page
