GPI
“GPI CONTROL” is used to enable and disable GPI functions and assign functions to each of the GPI
terminal pins (page 62).
The underlined values are factory preset setting values.
Sub menu Settings Description
GPI CONTROL
DISABLE
ENABLE
Enables and disables GPI functions
<DISABLE> Disabled
<ENABLE> Enabled
GPI1 - GPI8
UNDEF
MARKER1 ON/OFF
MARKER2 ON/OFF
MARKER BACK HALF
MARKER BACK BLACK
CENTER MARKER
INPUT SEL. VIDEO
INPUT SEL. SDI1
INPUT SEL. SDI2
INPUT SEL. HDMI
INPUT SEL. YP
B
P
R
INPUT SEL. VF
INPUT SEL. INT SG
SD ASPECT
SCAN
R-TALLY
G-TALLY
MONO
GAMMA SEL. FILM
GAMMA SEL. STDIO/PST
PIXEL TO PIXEL
FOCUS-IN-RED
REMOTE STANDBY
Assigns functions to the GPI control terminal pins.
The same items can be set to each terminal (page
62).
Note:
Operation may not be possible depending on the setting conditions.
Example: “SD ASPECT” operation when input signal is HD
Main Menu
(continued)
