Panasonic CF-29 - Page 17

X 2 H0J327200051 OSCILLATOR, 32.768KHz 1
X 5 H2D800400015 OSCILLATOR, 8MHz 1
X 6 H0J250500025 OSCILLATOR, 25MHz 1
IO PCB
C 701 702 703 704 705 706
708 710
F1G1H101A451 CAPACITOR, 50V, 100pF 8
C 707 709 711 712 713 714
715 716 717 718 719 720 721
722 723 724 725 726 727 730
732 733 734
F1G1H221A450 CAPACITOR, 50V, 220pF 23
C 728 729 731 F1G1H330A451 CAPACITOR, 50V, 33pF 3
C 735 F1G1C104A042 CAPACITOR, 16V, 0.1µF 1
CN 700 K1MN50A00001 CONNECTOR 1
CN 702 K1FB115B0074 CONNECTOR 1
CN 703 K1FB125B0080 CONNECTOR 1
CN 704 7734P-09G2 CONNECTOR 1
D 700 MA3X74800L DIODE 1
L 700 701 702 703 704 705
706 707
DDB5Z021G-Y INDUCTOR 8
L 708 709 710 711 712 713 DDB5Z024E-L INDUCTOR 7
PS 700 K5J1AB000001 POLY SW 1
R 704 705 706 707 708 709
710 711 712
ERJ2GEJ472X RESISTOR, 1/16W, 4.7KΩ 9
R 713 714 715 716 717 718
719 720
ERJ2GEJ102X RESISTOR, 1/16W, 1KΩ 8
LED PCB
CN 980 K1ZZ00000963 CONNECTOR 1
LD 1 2 3 6 7 B3ABB0000164 LED 5
LD 41 B3AGB0000040 LED 1
LD 5 B3ACB0000112 LED 1
KBD PCB
C 930 F1G1C104A042 CAPACITOR, 16V, 0.1µF 1
CN 930 FH12-50S05SH CONNECTOR 1
CN 931 K1MN16B00100 CONNECTOR 1
CN 932 K1MN16B00123 CONNECTOR 1
CN 933 K1MN13B00073 CONNECTOR 1
CN 934 K1MN07B00093 CONNECTOR 1
CN 950 951 952 953 K1QZA1AE0001 CONNECTOR 4
IC 930 C0JBAA000226 IC, LOGIC 1
TS PCB
C 850 858 DCUM1A1051BD CAPACITOR, 10V, 1µF 2
C 851 853 F1G1E472A062 CAPACITOR, 25V, 4700pF 2
C 852 854 F1G1H681A450 CAPACITOR, 50V, 680pF 2
C 855 859 F1G1C104A042 CAPACITOR, 16V, 0.1µF 2
C 856 857 F1G1H560A542 CAPACITOR, 50V, 56pF 2
CN 850 K1MN04B00012 CONNECTOR 1
CN 851 DFJP201ZA006 CONNECTOR 1
D 850 DED1SS355T17 DIODE 1
IC 850 C1DB00001042 TOUCH SCREEN CONTROLLER 1
Q 850 852 B1MBADA00003 TRANSISTOR 2
Q 851 UNR9113J0L TRANSISTOR 1
R 850 ERJ2GEJ224X RESISTOR, 1/16W, 220KΩ 1
R 851 854 ERJ2GEJ102X RESISTOR, 1/16W, 1KΩ 2
R 852 855 ERJ2GEJ822X RESISTOR, 1/16W, 8.2KΩ 2
R 853 ERJ2GEJ303X RESISTOR, 1/16W, 30KΩ 1
R 856 857 ERJ2GE0R00X RESISTOR, 1/16W, 0Ω 2
R 859 860 ERJ2GEJ222X RESISTOR, 1/16W, 2.2KΩ 2
RA 850 D1H8R0040009 RESISTOR ARRAY 1
X 850 H2D100500002 OSCILLATOR, 10MHz 1
TP PCB
