Panasonic CF-31JEGAXDM - Replacement Parts List - Other PCBs; WWAN RF SWITCH PCB Components; Other PCB Component Listings

R 2227 D1BA1432A022 RESISTOR, 1/16W, 14.3KΩ 1
R 2228, 2229, 2230 D1BDR047A111 RESISTOR, 1/3W, 0.047Ω 3
R 2231 D1BA3652A022 RESISTOR, 1/16W, 36.5KΩ 1
R 2232 D1BA4701A022 RESISTOR, 1/16W, 4.7KΩ 1
R 2233 D1BA1802A053 RESISTOR, 1/16W, 18KΩ 1
R 2234 D1BA6041A023 RESISTOR, 1/16W, 6.04KΩ 1
R 2236 D1BA6800A022 RESISTOR, 1/16W, 680Ω 1
R 2238, 2239, 2240 D1BDR075A111 RESISTOR, 1/3W, 0.075Ω 3
R 2242 D1BDR470A103 RESISTOR, 1/4W, 0.47Ω 1
R 2243 D1BB1623A075 RESISTOR, 1/10W, 162KΩ 1
R 2244, 2245 D1BA3001A022 RESISTOR, 1/16W, 3KΩ 2
R 2248 D0GA512JA023 RESISTOR, 1/16W, 5.1KΩ 1
R 2254, 2267, 2286 D1BA8202A022 RESISTOR, 1/16W, 82KΩ 3
R 2255 D1BA3301A023 RESISTOR, 1/16W, 3.3KΩ 1
R 2256 D1BA1602A022 RESISTOR, 1/16W, 16KΩ 1
R 2902, 2905, 2924, 2925 D0GA564JA023 RESISTOR, 1/16W, 560KΩ 4
R 2918, 2920 D0GA224JA023 RESISTOR, 1/16W, 220KΩ 2
T 1000, 1001 G5BYC0000015 TRANCE 2
X 2, 1002 H0J327200085 CRYSTAL OSCILLATOR 2
X 3, 7 H0J2505A0053 CRYSTAL OSCILLATOR 2
X 1001 H0J245500096 CRYSTAL OSCILLATOR 1
X 1003 H0J240500051 CRYSTAL OSCILLATOR 1
ZA 1, 2 K1YGZZ000082 STUD 2
ZA 3, 4 K1YGZZ000088 PARTS FOR CONNECTOR AND ACCESSORY 2
ZA 704, 705 K1YGZZ000078 MINI PCI EXPRESS STUD BOS 2
WWAN RF SWITCH PCB
C 304 F1J1A106A043 CAPACITOR, 10V, 10µF 1
C 305, 306, 308, 512, 517,
518, 554
F1G1C104A048 CAPACITOR, 16V, 0.1µF 7
C 307 F1G1H1010005 CAPACITOR, 50V, 100pF 1
C 500, 501, 505, 519, 520,
536, 537, 553
F1G1H270A542 CAPACITOR, 50V, 27pF 8
C 502, 509 F1G1H100A544 CAPACITOR, 50V, 10pF 2
C 503, 504, 510, 511, 522,
523, 528, 529, 551, 552
F1G1H102A496 CAPACITOR, 50V, 1000pF 10
C 513, 514 F1H1A1050015 CAPACITOR, 10V, 1µF 2
C 527, 530, 531, 540, 548,
549
F1G1H560A542 CAPACITOR, 50V, 56pF 6
C 556 F1G1E103A062 CAPACITOR, 25V, 0.01µF 1
CN 301 K1MY40BA0431 CONNECTER 1
CN 302 K1MY52B00004 WLAN MODULE MINI PCI EXPRESS CONNECTOR 1
CN 303 K1NA08E00013 SIM CONNECTOR 1
CN 304 K1MN10BA0059 CONNECTOR 1
IC 514, 515, 516 C0JBAB000832 IC, LOGIC 3
IC 517, 518, 520, 523 C1CB00003592 SPDT SWITCH 4
IC 519 C1CB00002845 SPDT SWITCH 1
IC 522 C1CB00002842 SPDT SWITCH 1
JK 305, 306, 307, 500, 501,
502, 503, 504, 505, 508,
509
,
510
,
511
K1QZA1AE0001 CONNECTOR 13
L 500 G1C27NJA0024 CHIP INDUCTOR 1
PA 500 S D4FBR2000003 POLY SWITCH 1
Q 500 B1GBCFNN0042 TRANSISTOR 1
Q 501 B1CHRC000024 SILICON P CHANNEL MOSFET 1
R 301, 303, 304 D0GAR00J0005 RESISTOR, 1/16W, 0Ω 3
R 305, 308, 309, 507 D0GA103JA023 RESISTOR, 1/16W, 10KΩ 4
R 306, 307, 310 D0GA101JA023 RESISTOR, 1/16W, 100Ω 3
28/31
