Panasonic CQ-TX5500W

Ref.
No.
Part No. Part Name & Description Remarks
C638 YECUZ1C104KX Ceramic, 0.1µF 16WV
C640 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C641 YECUS1H102KX Ceramic, 0.001µF 50WV
C643 EEUFC1C471L Electrolytic, 470µF 16WV
C644 YECUZ1C104KX Ceramic, 0.1µF 16WV
C645 ECA1CM100I Electrolytic, 10µF 16WV
C646 YECUZ1H103KX Ceramic, 0.01µF 50WV
C648 YECUZ1H103KX Ceramic, 0.01µF 50WV
C649 YECUZ1C104KX Ceramic, 0.1µF 16WV
C654 YECUS1C224KX Ceramic, 0.22µF 16WV
C655 YECUS1C224KX Ceramic, 0.22µF 16WV
C659 YECUS1H103KX Ceramic, 0.01µF 50WV
C660 YECUS1H103KX Ceramic, 0.01µF 50WV
C670 ECEA1HKA010I Electrolytic, 1µF 50WV
C671 YECUZ1C104KX Ceramic, 0.1µF 16WV
C673 YECUZ1C104KX Ceramic, 0.1µF 16WV
C674 YECUZ1C104KX Ceramic, 0.1µF 16WV
C680 YECUS1H103KX Ceramic, 0.01µF 50WV
C701 YECUS1C104KX Ceramic, 0.1µF 16WV
C703 EEUPL1C332Z Electrolytic, 3300µF 16WV
C705 ECA1CHG102B Electrolytic, 1000µF 16WV
C707 YECUS1C105ZF Ceramic, 1µF 16WV
C708 YECUS1C104KX Ceramic, 0.1µF 16WV
C709 YECUS1C104KX Ceramic, 0.1µF 16WV
C710 ECA1CHG101I Electrolytic, 100µF 16WV
C711 YECUS1H103KX Ceramic, 0.01µF 50WV
C712 EEUFC1A820 Electrolytic, 82µF 10WV
C717 YECUS1H103KX Ceramic, 0.01µF 50WV
C718 YECUS1H103KX Ceramic, 0.01µF 50WV
C719 YECUS1C104KX Ceramic, 0.1µF 16WV
C720 ECEA1CKA470I Electrolytic, 47µF 16WV
C722 YECUS1C104KX Ceramic, 0.1µF 16WV
C723 ECEA1CKA220I Electrolytic, 22µF 16WV
C724 ECEA1AKA220I Electrolytic, 22µF 10WV
C725 ECEA1CKA220I Electrolytic, 22µF 16WV
C726 YECUS1C104KX Ceramic, 0.1µF 16WV
C727 ECA1CM471B Electrolytic, 470µF 16WV
C728 YECUS1C104KX Ceramic, 0.1µF 16WV
C730 ECEA1CPU222L Electrolytic, 2200µF 16WV
C731 YECUS1H103KX Ceramic, 0.01µF 50WV
C732 ECA1CM101I Electrolytic, 100µF 16WV
C733 ECSH1EC475CR Tantalum, 4.7µF 25WV
C739 ECEA1AKA221I Electrolytic, 220µF 10WV
C746 YECUS1C104KX Ceramic, 0.1µF 16WV
C747 ECEA1AKA221I Electrolytic, 220µF 10WV
C748 ECSH1CX475CR Tantalum, 4.7µF 16WV
C763 EEUPL1C332Z Electrolytic, 3300µF 16WV
C765 ECA1CAD100XI Electrolytic, 10µF 16WV
C766 ECA1CAD100XI Electrolytic, 10µF 16WV
C768 YECUS1H103KX Ceramic, 0.01µF 50WV
C769 YECUS1C104KX Ceramic, 0.1µF 16WV
C781 YECUS1C104KX Ceramic, 0.1µF 16WV
C790 YECUS1H103KX Ceramic, 0.01µF 50WV
C791 ECEA1CKA101 Electrolytic, 100µF 16WV
C792 ECA1AHG331I Electrolytic, 330µF 10WV
C793 YECUS1C104KX Ceramic, 0.1µF 16WV
C801 YECUS1C104KX Ceramic, 0.1µF 16WV
C802 YECUS1H103KX Ceramic, 0.01µF 50WV
C803 YECUS1C104KX Ceramic, 0.1µF 16WV
C804 ECEA0JKA331I Electrolytic, 330µF 6.3WV
C805 YECUS1C104KX Ceramic, 0.1µF 16WV
C806 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C807 YECUS1C104KX Ceramic, 0.1µF 16WV
C808 ECA1CM331B Electrolytic, 330µF 16WV
C815 ECA1CM471B Electrolytic, 470µF 16WV
C816 YECUS1C104KX Ceramic, 0.1µF 16WV
C817 YECUS1H103KX Ceramic, 0.01µF 50WV
C851 EEUFC1H390H Electrolytic, 39µF 50WV
C852 EEUFC1H390H Electrolytic, 39µF 50WV
C853 EEUFC1H390H Electrolytic, 39µF 50WV
C854 ECA2EHG100B Electrolytic, 10µF 250WV
C855 ECA2AM010I Electrolytic, 1µF 100WV
C856 ECA2AM010I Electrolytic, 1µF 100WV
Ref.
No.
Part No. Part Name & Description Remarks
C858 YECUS1C104KX Ceramic, 0.1µF 16WV
C859 EEUFC1A181H Electrolytic, 180µF 10WV
C860 YECUS1C104KX Ceramic, 0.1µF 16WV
C861 EEUFC1A181H Electrolytic, 180µF 10WV
C864 YECUS1C104KX Ceramic, 0.1µF 16WV
C865 YECUS1C104KX Ceramic, 0.1µF 16WV
C866 YECUS1H271JM Ceramic, 270PF 50WV
C867 YECUS1C104KX Ceramic, 0.1µF 16WV
C868 ECA1HHG100I Electrolytic, 10µF 50WV
C869 EEFCD1B220R Electrolytic, 22µF 12.5WV
C873 ECA2CHG4R7I Electrolytic, 4.7µF 160WV
C874 ECA1CHG102B Electrolytic, 1000µF 16WV
C887 YECUS1H103KX Ceramic, 0.01µF 50WV
C889 ECEA1AKA221I Electrolytic, 220µF 10WV
C890 ECEA1AKA221I Electrolytic, 220µF 10WV
C900 YECUZ1C104KX Ceramic, 0.1µF 16WV
RESISTORs
R200 D0YFR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R201 D0GD564JA012 Metal Film, 560kΩ
ΩΩ
Ω 1/10W
R202 ERJ14YJ822H Chip, 8.2kΩ
ΩΩ
Ω 1/4W
R203 D0GF470JA007 Metal Film, 47Ω
ΩΩ
Ω 1/10W
R205 D0GD681JA012 Metal Film, 680Ω
ΩΩ
Ω 1/10W
R206 D0GD681JA012 Metal Film, 680Ω
ΩΩ
Ω 1/10W
R207 D0GB333JA006 Metal Film, 33kΩ
ΩΩ
Ω 1/10W
R210 D0GD223JA012 Metal Film, 22kΩ
ΩΩ
Ω 1/10W
R211 D0GD183JA012 Metal Film, 18kΩ
ΩΩ
Ω 1/10W
R217 D0GD223JA012 Metal Film, 22kΩ
ΩΩ
Ω 1/10W
R218 D0GD183JA012 Metal Film, 18kΩ
ΩΩ
Ω 1/10W
R220 D0YFR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R221 D0GB123JA006 Metal Film, 12kΩ
ΩΩ
Ω 1/10W
R222 D0GB752JA006 Metal Film, 7.5kΩ
ΩΩ
Ω 1/10W
R223 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R224 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R226 D0GD104JA012 Metal Film, 100kΩ
ΩΩ
Ω 1/10W
R227 D0GD153JA012 Metal Film, 15kΩ
ΩΩ
Ω 1/10W
R228 D0GD153JA012 Metal Film, 15kΩ
ΩΩ
Ω 1/10W
R229 D0GB912JA006 Metal Film, 9.1kΩ
ΩΩ
Ω 1/10W
R230 D0GB752JA006 Metal Film, 7.5kΩ
ΩΩ
Ω 1/10W
R231 D0GB223JA006 Metal Film, 22kΩ
ΩΩ
Ω 1/10W
R232 D0YBR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R233 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R234 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R235 D0GB333JA006 Metal Film, 33kΩ
ΩΩ
Ω 1/10W
R242 D0GB222JA006 Metal Film, 2.2kΩ
ΩΩ
Ω 1/10W
R244 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R252 D0GD393JA012 Metal Film, 39kΩ
ΩΩ
Ω 1/10W
R253 D0GD333JA012 Metal Film, 33kΩ
ΩΩ
Ω 1/10W
R254 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R255 D0GD222JA012 Metal Film, 2.2kΩ
ΩΩ
Ω 1/10W
R256 D0GD393JA012 Metal Film, 39kΩ
ΩΩ
Ω 1/10W
R258 D0GD333JA012 Metal Film, 33kΩ
ΩΩ
Ω 1/10W
R261 D0GB472JA006 Metal Film, 4.7kΩ
ΩΩ
Ω 1/10W
R262 D0GB472JA006 Metal Film, 4.7kΩ
ΩΩ
Ω 1/10W
R263 D0GD332JA012 Metal Film, 3.3kΩ
ΩΩ
Ω 1/10W
R264 D0GB332JA006 Metal Film, 3.3kΩ
ΩΩ
Ω 1/10W
R265 D0GD223JA012 Metal Film, 22kΩ
ΩΩ
Ω 1/10W
R266 D0GB102JA006 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
R271 D0GB332JA006 Metal Film, 3.3kΩ
ΩΩ
Ω 1/10W
R272 D0GB332JA006 Metal Film, 3.3kΩ
ΩΩ
Ω 1/10W
R273 D0GB682JA006 Metal Film, 6.8kΩ
ΩΩ
Ω 1/10W
R274 D0GD562JA012 Metal Film, 5.6kΩ
ΩΩ
Ω 1/10W
R276 D0GD121JA012 Metal Film, 120Ω
ΩΩ
Ω 1/10W
R277 D0YDR0000016 Resistor, 0Ω
ΩΩ
Ω 1/8W
R279 D0GD471JA012 Metal Film, 470Ω
ΩΩ
Ω 1/10W
R280 D0GB225JA006 Metal Film, 2.2MΩ
ΩΩ
Ω 1/10W
R281 D0GD103JA012 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R282 D0GB473JA006 Metal Film, 47kΩ
ΩΩ
Ω 1/10W
R283 D0GB223JA006 Metal Film, 22kΩ
ΩΩ
Ω 1/10W
R284 D0GB102JA006 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
R285 D0GB154JA006 Metal Film, 150kΩ
ΩΩ
Ω 1/10W
15
CQ-TX5500W
