Panasonic CQ-TX5500W - Page 18

Ref.
No.
Part No. Part Name & Description Remarks
D912 B3ACB0000066 LED
D913 B3ACB0000066 LED
D914 B3ACB0000066 LED
D915 B3ACB0000066 LED
D916 B3ACB0000066 LED
D917 B3ACB0000066 LED
D918 B3ACB0000066 LED
D919 B3ACB0000066 LED
D920 LNJ412K82RA4 LED
D921 LNJ412K82RA4 LED
D922 LNJ412K82RA4 LED
D923 LNJ412K82RA4 LED
D924 LNJ412K82RA4 LED
D933 B3AFB0000033 LED
D953 MAZ80390LL Diode
D960 MA159TX Diode
D961 MA159TX Diode
D962 MA159TX Diode
D993 LNJ412K82RA4 LED
DA901 B0ZBZ0000053 Diode
DA902 B0ZBZ0000053 Diode
DA903 B0ZBZ0000053 Diode
CAPACITORs
C899 ECA2CHG100 Electrolytic, 10µF 160WV
C901 YECUZ1C104KX Ceramic, 0.1µF 16WV
C902 YECUZ1C104KX Ceramic, 0.1µF 16WV
C903 YECUZ1C104KX Ceramic, 0.1µF 16WV
C904 YECUZ1C104KX Ceramic, 0.1µF 16WV
C905 YECUZ1C104KX Ceramic, 0.1µF 16WV
C906 YECUZ1H221JC Ceramic, 220PF 50WV
C907 YECSV1CM225R Tantalum, 2.2µF 16WV
C908 YECUS1H102KX Ceramic, 0.001µF 50WV
C909 YECUS1C224KX Ceramic, 0.22µF 16WV
C910 YECUS1C224KX Ceramic, 0.22µF 16WV
C911 YECUS1H102KX Ceramic, 0.001µF 50WV
C912 YECUS1H102KX Ceramic, 0.001µF 50WV
C914 YECUZ1H103KX Ceramic, 0.01µF 50WV
C915 YECUZ1C104KX Ceramic, 0.1µF 16WV
C952 YECUZ1C104KX Ceramic, 0.1µF 16WV
C953 YECUZ1C104KX Ceramic, 0.1µF 16WV
C954 YECUZ1C104KX Ceramic, 0.1µF 16WV
C955 YECUZ1C104KX Ceramic, 0.1µF 16WV
C956 YECUZ1C104KX Ceramic, 0.1µF 16WV
C960 YECUZ1C104KX Ceramic, 0.1µF 16WV
C961 YECUZ1H562KX Ceramic, 0.0056µF 50WV
C962 YECUZ1H562KX Ceramic, 0.0056µF 50WV
C963 YECUZ1H562KX Ceramic, 0.0056µF 50WV
C964 YECUZ1C104KX Ceramic, 0.1µF 16WV
RESISTORs
R295 D0YBR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R296 D0YBR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R395 D0YBR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R396 D0YBR0000011 Resistor, 0Ω
ΩΩ
Ω 1/8W
R901 D0GD202JA012 Metal Film, 2kΩ
ΩΩ
Ω 1/10W
R902 D0GD202JA012 Metal Film, 2kΩ
ΩΩ
Ω 1/10W
R903 D0GD202JA012 Metal Film, 2kΩ
ΩΩ
Ω 1/10W
R904 D0GD271JA012 Metal Film, 270Ω
ΩΩ
Ω 1/10W
R906 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R907 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R908 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R909 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R910 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R911 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R912 D0GD331JA012 Metal Film, 330Ω
ΩΩ
Ω 1/10W
R920 D0YDR0000016 Resistor, 0Ω
ΩΩ
Ω 1/8W
R931 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
Ref.
No.
Part No. Part Name & Description Remarks
R932 D0GB103JA006 Metal Film, 10kΩ
ΩΩ
Ω 1/10W
R933 D0GB101JA006 Metal Film, 100Ω
ΩΩ
Ω 1/10W
R934 D0GB102JA006 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
R935 D0YDR0000016 Resistor, 0Ω
ΩΩ
Ω 1/8W
R954 D0GB102JA006 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
R955 D0GB333JA006 Metal Film, 33kΩ
ΩΩ
Ω 1/10W
R969 D0GB332JA006 Metal Film, 3.3kΩ
ΩΩ
Ω 1/10W
R970 D0GB102JA006 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
R971 D0GB473JA006 Metal Film, 47kΩ
ΩΩ
Ω 1/10W
R991 D0GF102JA007 Metal Film, 1kΩ
ΩΩ
Ω 1/10W
CONNECTORs
CN311 YEAETKCF08RS Connector, 8P
CN312 K1KB10A00057 Connector, 10P
CN350 YEAETKCF06XE Connector, 6P
CN901 K1KB14A00042 Connector, 14P
CN902 YEAETKCF12XE Connector, 12P
CN903 YEAE5339806 Connector, 6P
CN904 YEAE5339806 Connector, 6P
CN905,
906
K1KA10A00073 Connector, 10P
CN907 YEAE5339804 Connector, 4P
CN908 K1PZ04D00001 Connector, 4P
SWITCHEs
SW901 YEAS09312 Switch
SW902 YEAS09312 Switch
SW903 YEAS09312 Switch
SW904 YEAS09312 Switch
SW905 YEAS09312 Switch
SW906 YEAS09312 Switch
SW907 YEAS09312 Switch
SW908 YEAS09312 Switch
SW909 YEAS09312 Switch
SW910 YEAS09312 Switch
SW911 YEAS09312 Switch
SW920 YEAS09312 Switch
SW921 K9AA01800003 Switch
SW922 K9ZZ00000960 Self return switch
SW925 YEAS08041A Switch
LCD
LCD901 L5AABGB00003 LCD Display
RESISTOR NETWORKs
RA901 EXBV8V102JV Resistor Network
RA902 EXBV8V103JV Resistor Network
RA903 EXBV8V102JV Resistor Network
[E-9068B] CD Servo Block
ICs AND TRANSISTORs
IC101 C1BB00000624 IC
IC401 MN6627482WB IC
IC441 C0JBAE000087 IC
IC451 MN1933222MF IC
IC501 MN101C28LAC2 IC
IC531 YEAM7200U33T IC
IC541 YEAMT7ST32UL IC
IC551 C3BBHG000053 IC
IC901 C0GBY0000012 IC
Q1 B3HB00000012 Transistor
Q3 B3HB00000012 Transistor
18
CQ-TX5500W
